N3300 Series High Power Programmable DC Power Supply

N3300 series is developed based on NGI's years of experience in testing for electric vehicles/motors, battery/supercapacitor packs, BMS, CMS, solar inverters, DC/DC converters, consumer electronics,etc. According to different test environments in the fields of lab test, system integration test, and mass production line, NGI has made a number of optimization designs based on the international advanced technology. N3300 series is with high-power, high-current, low ripple noise, high cost-effective and full-featured.

Search by model
Showing 0 results
ModelChannel NumberVoltageCurrent PowerAccuracyResolution Communication InterfaceSize
N3305-60160V83.3A5,000WVoltage≤0.05%+0.1%F.S./Current≤0.1%+0.1%F.S.1mV/1.4mALAN/RS2323U
N3305-1501150V33.3A5,000WVoltage≤0.05%+0.1%F.S./Current≤0.1%+0.1%F.S.2.5mV/0.6mALAN/RS2323U
N3305-3001300V16.6A5,000WVoltage≤0.05%+0.1%F.S./Current≤0.1%+0.1%F.S.5mV/0.3mALAN/RS2323U
N3305-4501450V11.1A5,000WVoltage≤0.05%+0.1%F.S./Current≤0.1%+0.1%F.S.7.5mV/0.2mALAN/RS2323U
N3305-6001600V8.3A5,000WVoltage≤0.05%+0.1%F.S./Current≤0.1%+0.1%F.S.10mV/0.2mALAN/RS2323U
N3305-8001800V6.2A5,000WVoltage≤0.05%+0.1%F.S./Current≤0.1%+0.1%F.S.14mV/0.2mALAN/RS2323U
N3305-100011000V5A5,000WVoltage≤0.05%+0.1%F.S./Current≤0.1%+0.1%F.S.17mV/0.1mALAN/RS2323U
N3310-60160V166.6A10,000WVoltage≤0.05%+0.1%F.S./Current≤0.1%+0.1%F.S.1mV/2.8mALAN/RS2323U
N3310-1501150V66.6A10,000WVoltage≤0.05%+0.1%F.S./Current≤0.1%+0.1%F.S.2.5mV/1.2mALAN/RS2323U
N3310-3001300V33.3A10,000WVoltage≤0.05%+0.1%F.S./Current≤0.1%+0.1%F.S.5mV/0.6mALAN/RS2323U
N3310-4501450V22.2A10,000WVoltage≤0.05%+0.1%F.S./Current≤0.1%+0.1%F.S.7.5mV/0.4mALAN/RS2323U
N3310-6001600V16.6A10,000WVoltage≤0.05%+0.1%F.S./Current≤0.1%+0.1%F.S.10mV/0.3mALAN/RS2323U
N3310-8001800V12.5A10,000WVoltage≤0.05%+0.1%F.S./Current≤0.1%+0.1%F.S.14mV/0.3mALAN/RS2323U
N3310-100011000V10A10,000WVoltage≤0.05%+0.1%F.S./Current≤0.1%+0.1%F.S.17mV/0.2mALAN/RS2323U
N3315-60160V250A15,000WVoltage≤0.05%+0.1%F.S./Current≤0.1%+0.1%F.S.1mV/4.2mALAN/RS2323U
N3315-1501150V100A15,000WVoltage≤0.05%+0.1%F.S./Current≤0.1%+0.1%F.S.2.5mV/1.7mALAN/RS2323U
N3315-3001300V50A15,000WVoltage≤0.05%+0.1%F.S./Current≤0.1%+0.1%F.S.5mV/0.9mALAN/RS2323U
N3315-4501450V33.3A15,000WVoltage≤0.05%+0.1%F.S./Current≤0.1%+0.1%F.S.7.5mV/0.6mALAN/RS2323U
N3315-6001600V25A15,000WVoltage≤0.05%+0.1%F.S./Current≤0.1%+0.1%F.S.10mV/0.42mALAN/RS2323U
N3315-8001800V18.7A15,000WVoltage≤0.05%+0.1%F.S./Current≤0.1%+0.1%F.S.14mV/0.4mALAN/RS2323U
N3315-100011000V15A15,000WVoltage≤0.05%+0.1%F.S./Current≤0.1%+0.1%F.S.17mV/0.3mALAN/RS2323U
N3330-60160V500A30,000WVoltage≤0.05%+0.1%F.S./Current≤0.1%+0.1%F.S.1mV/8.4mALAN/RS2326U
N3330-1501150V200A30,000WVoltage≤0.05%+0.1%F.S./Current≤0.1%+0.1%F.S.2.5mV/3.4mALAN/RS2326U
N3330-3001300V100A30,000WVoltage≤0.05%+0.1%F.S./Current≤0.1%+0.1%F.S.5mV/1.7mALAN/RS2326U
N3330-4501450V66.6A30,000WVoltage≤0.05%+0.1%F.S./Current≤0.1%+0.1%F.S.7.5mV/1.2mALAN/RS2326U
N3330-6001600V50A30,000WVoltage≤0.05%+0.1%F.S./Current≤0.1%+0.1%F.S.10mV/0.9mALAN/RS2326U
N3330-8001800V37.5A30,000WVoltage≤0.05%+0.1%F.S./Current≤0.1%+0.1%F.S.14mV/0.7mALAN/RS2326U
N3330-100011000V30A30,000WVoltage≤0.05%+0.1%F.S./Current≤0.1%+0.1%F.S.17mV/0.5mALAN/RS2326U
Features

■  5kW/10kW/15kW high power density chassis design

■  Support cascade of multiple devices, Max. 150kW

■  Standard voltage: 60V/150V/300V/450V/600V/800V/1000V

■  Multiple protections: OCP, OVP, UVP, OTP, OPP, reverse polarity and monitoring mode

■  High power density, minimizing space occupation

■  CV mode / CP mode

■  Programmable sequence test function(SEQ), up to 100 groups sequence files, up to 100 steps per file

■  Editable rise/fall slew rate

■  Remote sense

■  Power-off memory function

■  Big LCD screen for information display

■  Intelligent fan control with ultra-low noise to offer comfort

■  Built-in auto test function, one-button operation for complex test tasks

■  Analog programming interface(APG), current monitoring interface, remote trigger function to realize complex function control and monitoring

■  Support SCPI command communication and programming Driverlib

■  Support LAN and RS232 interface

■  Standard 19-inch 3U, available for cabinet installation

Functions & Advantages

Operation Mode

The operation mode includes CV and CP mode.



Master/slave design, more convenient for power expansion

N3300 can be used independently or in master/slave parallel operation. It has built-in master/slave mode, and the Max. power can be expanded to 75kW. It adopts a unique current sharing design to ensure each module shares the load equally and ensure the consistency of product use.



External Interfaces

N3300 provides a number of external interfaces, including voltage/current monitoring output, voltage/current setting input, power control input signal, and four TTL output signals, etc. The standard communication interfaces are LAN and RS232.



Voltage Rise and Fall Waveform



Voltage & Current Monitoring

The voltage/current monitoring output terminals output 0-reference voltage, corresponding to 0-full scale. An electric meter or oscilloscope can be connected externally to monitor the voltage/current variation.

Application Fields
Dimension
Standard & Optional Accessories
Database

Data Sheet

User Manual

Communication Protocol

Software & Driver

Application

Related Products
