N6140 Series Four-channel Multifunctional DC Electronic Load

N6140 series is developed based on NGI's years of experience in testing for power supply and battery. It is with high accuracy, high reliability, high integration, high cost-effective and full features in CC, CV, CP, and CR. N6140 series is tailored for integrated applications, featuring easy integration and high stability. In most integrated applications, N6140 series can replace low-power standalone electronic loads and save much cost for users.

N6140 series is specifically designed for embedded integrated applications, with 19-inch 2U/3U size and LAN port, and providing drive program. It supports secondary development of most software, such as Visual C ++, C #, Delphi, Visual Basic, Labview, etc. Users can customize the application software as needed.


Search by model
Showing 0 results
ModelChannel NumberVoltageCurrent PowerAccuracyResolution Communication InterfaceSize
N6140AP420V5A50WVoltage≤0.015%+0.03%F.S./Current≤0.015%+0.03%F.S.0.01mV/0.001mALAN2U
N6141BP460V30A180WVoltage≤0.015%+0.03%F.S./Current≤0.015%+0.03%F.S.0.03mV/0.01mALAN2U
N6142BP4150V30A180WVoltage≤0.015%+0.03%F.S./Current≤0.015%+0.03%F.S.0.06mV/0.01mALAN2U
N6140CP460V60A360WVoltage≤0.015%+0.03%F.S./Current≤0.015%+0.03%F.S.0.03mV/0.02mALAN3U
N6141CP4150V60A360WVoltage≤0.015%+0.03%F.S./Current≤0.015%+0.03%F.S.0.06mV/0.02mALAN3U
N6142CP4600V15A360WVoltage≤0.015%+0.03%F.S./Current≤0.015%+0.03%F.S.0.3mV/0.005mALAN3U
N6140DP460V90A540WVoltage≤0.015%+0.03%F.S./Current≤0.015%+0.03%F.S.0.03mV/0.03mALAN3U
N6141DP4150V90A540WVoltage≤0.015%+0.03%F.S./Current≤0.015%+0.03%F.S.0.06mV/0.03mALAN3U
N6142DP4600V30A540WVoltage≤0.015%+0.03%F.S./Current≤0.015%+0.03%F.S.0.3mV/0.01mALAN3U
N6140AE420V5A50WVoltage≤0.015%+0.03%F.S./Current≤0.015%+0.03%F.S.0.01mV/0.001mALAN2U
N6141BE460V30A180WVoltage≤0.015%+0.03%F.S./Current≤0.015%+0.03%F.S.0.03mV/0.01mALAN2U
N6142BE4150V30A180WVoltage≤0.015%+0.03%F.S./Current≤0.015%+0.03%F.S.0.06mV/0.01mALAN2U
N6140CE460V60A360WVoltage≤0.015%+0.03%F.S./Current≤0.015%+0.03%F.S.0.03mV/0.02mALAN3U
N6141CE4150V60A360WVoltage≤0.015%+0.03%F.S./Current≤0.015%+0.03%F.S.0.06mV/0.02mALAN3U
N6142CE4600V15A360WVoltage≤0.015%+0.03%F.S./Current≤0.015%+0.03%F.S.0.3mV/0.005mALAN3U
N6140DE460V90A540WVoltage≤0.015%+0.03%F.S./Current≤0.015%+0.03%F.S.0.03mV/0.03mALAN3U
N6141DE4150V90A540WVoltage≤0.015%+0.03%F.S./Current≤0.015%+0.03%F.S.0.06mV/0.03mALAN3U
N6142DE4600V30A540WVoltage≤0.015%+0.03%F.S./Current≤0.015%+0.03%F.S.0.3mV/0.01mALAN3U
Features
■  Power range: 60W/180W/360W/540W
■  Voltage range: 0-20V/0-60V/0-150V/0-600V
■  Current range: 0-5A/0-15A/0-30A/0-60A/0-90A
■  Operation mode: CC、CV、CP、CR、CCD
■  Von/Voff setting
■  Dynamic frequency sweep (Optional)
■  Load effect test(Optional)
■  Short-circuit simulation
■  Milliohm meter function(Optional)
■  Voltage ripple measurement(Optional)
■  Time measurement(Optional)
■  Convenient OCP/OVP/OPP test(Optional)
■  High-speed LAN port
■  Multiple protection: OCP/OVP/OPP/OTP
■  Each channel isolated
■  High reliability, long MTBF(mean time between failure)
■  Standard 19-inch 2U, available for cabinet installation
Functions & Advantages

Dynamic frequency sweep

Dynamic frequency sweep is similar to transient mode, repeatedly switching between two parameters. The duration of each parameter is determined by the sweep frequency and duty ratio. It increases from the initial sweep frequency to the cut-off frequency. The frequency increment and frequency point sweep duration are settable. During the sweep, the input voltage is accompanied by a current transient, which causes overshoot and drop. With the functions of voltage ripple and peak-to-peak measurement, various dynamic parameters and corresponding frequencies can be obtained.



Voltage ripple measurement

By adjusting the voltage and current signals, the peak-to-peak value of the ripple and the effective value can be calculated according to the actual needs via professional algorithm. Combined with the waveform export function, various parameters such as the ripple frequency component can be further analyzed.



Time measurement

Within the predetermined load conditions and parameter ranges, N6140 will record the time point of two triggers by setting two values or some event (such as Vmax) as the trigger source. N6140 will then calculate the interval between two triggers.



Powerful automatic test

The automatic test can rapidly obtain various parameters. No manual intervention is required after the test procedures and parameters are set in advance. In this way, the efficiency of the production line can be greatly improved and large-scale automation integration can be achieved.

Application Fields
